RXEF005 Tyco Electronics
Same model may have multiple batches, images only for reference.

RXEF005

Part No RXEF005
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 60V 50MA RADIAL / Polymeric PTC Resettable Fuse 60V 50 mA Ih Through Hole Radial, Disc
Datasheet
RXEF005 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - PTC Resettable Fuses
Mfr Littelfuse Inc.
Series PolySwitch®, RXEF
Package Bag
Product Status Active
Type Polymeric
Voltage - Max 60V
Current - Hold (Ih) (Max) 50 mA
Current - Trip (It) 100 mA
Current - Max 40 A
Time to Trip 5 s
Resistance - Initial (Ri) (Min) 7.3 Ohms
Resistance - Post Trip (R1) (Max) 20 Ohms
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Through Hole
Package / Case Radial, Disc
Size / Dimension 0.315" Dia x 0.118" T (8.00mm x 3.00mm)
Height - Seated (Max) 0.327" (8.30mm)
Lead Spacing 0.199" (5.05mm)
Approval Agency CQC, CSA, TUV, UL
Standard Package 500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
California Prop 65 Warning Information
Win Source Part Number 662106-RXEF005
Ultra Librarian 3D Model Ultra Librarian RXEF005 CAD Model

Description

The 662106-RXEF005 is a PolySwitch resettable fuse designed for circuit protection. Bold text: 662106-RXEF005 from Littelfuse Inc.

  • Series: PolySwitch RXEF
  • Voltage Rating: 60V
  • Current Rating: 40A
  • Hold Current (Ih): 50mA
  • Trip Current (It): 100mA
  • Time to Trip: 5 seconds
  • Mounting: Through-Hole
  • Package: Radial Disc
  • Operating Temperature: -40°C to 85°C
  • Resistance (Initial): 7.3 Ohms
  • Resistance (Post Trip): 20 Ohms
  • Product Status: Active
  • Approvals: CQC, CSA, TUV, UL
