APT2012SRCPRV Kingbright Corporation
Same model may have multiple batches, images only for reference.

APT2012SRCPRV

Part No APT2012SRCPRV
Manufacturer Kingbright Corporation
Catalog LED Indication - Discrete
Description LED RED CLEAR CHIP SMD
Datasheet
APT2012SRCPRV Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - LED Indication - Discrete
Mfr Kingbright Corporation
Package Tape & Reel
Product Status Obsolete
Color Red
Configuration Standard
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 30mcd
Lens Style Rectangle with Flat Top
Lens Size 1.30mm x 1.25mm
Voltage - Forward (Vf) (Typ) 1.85V
Current - Test 20mA
Viewing Angle 120°
Mounting Type Surface Mount
Wavelength - Dominant 640nm
Wavelength - Peak 655nm
Package / Case 0805 (2012 Metric)
Supplier Device Package Chip LED
Size / Dimension 2.00mm L x 1.25mm W
Height (Max) 0.75mm
Base Product Number APT2012
Standard Package 2,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 563971-APT2012SRCPRV
Ultra Librarian 3D Model Ultra Librarian APT2012SRCPRV CAD Model

Description

The APT2012SRCPRV is a surface mount chip LED with a rectangular lens style supplied by Kingbright Corporation.

  • Lens Transparency: Clear
  • Light Color: Red
  • Dominant Wavelength: 640nm
  • Viewing Angle: 120°
  • Millicandela Rating: 30mcd
  • Forward Voltage: 1.85V
  • Forward Current: 20mA
  • Package: 0805 (2012 Metric)
  • Standard Package: 2,000 pieces
  • Applications: Display panels, indicator lights, and signage applications
