EC2-12NU Real Image EC2-12NU real image3735 EC2-12NU Real Image1 EC2-12NU Real Image2 EC2-12NU Real Image3
EC2-12NU Real Image EC2-12NU real image3735 EC2-12NU Real Image1 EC2-12NU Real Image2 EC2-12NU Real Image3
Same model may have multiple batches, images only for reference.

EC2-12NU

Part No EC2-12NU
Manufacturer Kemet
Catalog Signal Relays, Up to 2 Amps
Description Signal Relay 12VDC 2A DPDT( (15mm 7.5mm 9.4mm)) THT / RELAY GEN PURPOSE DPDT 2A 12V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Kemet
Packaging Tube/Rail
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 11.7mA
Coil Voltage 12VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 9 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 2ms
Release Time 1ms
Mounting Through Hole
Termination Style PC Pin
Coil Power 140 mW
Coil Resistance 1.03 kOhms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 080861-EC2-12NU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name EC2-12NU
ECCN EAR99
Country of Origin Japan
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian EC2-12NU CAD Model

Description

EC2-12NU - Multi-Purpose Relay Module

The EC2-12NU is a versatile relay module designed for industrial and commercial applications, offering dependable performance in automation systems.

  • Applications:
  • Industrial control systems
  • Home automation
  • Power management solutions

Features and Benefits:

  • Stable coil resistance providing robust operation
  • Compact size for integration into various devices
  • High electrical endurance for prolonged usage

Additional Details:
This relay module is built to withstand fluctuating environmental conditions, enhancing control systems' reliability.
