The B4B-XH-AM(LF)(SN) is a 4-position, top entry, shrouded header from JST's XH series of wire-to-board connectors. These connectors are known for their compact size, high reliability, and ease of use, making them a popular choice in a wide range of electronic applications. The (LF)(SN) designation indicates that the connector is lead-free and features a tin (Sn) plating.

Applications

• Signal circuits in electronic equipment
• Power supply connections
• Data transmission interfaces
• Internal wiring of consumer electronics
• Industrial control systems

Features

• 4 Positions
• Top entry orientation
• Shrouded header design
• XH series connector
• Tin (Sn) plating
• Lead-free construction
• Polarized mating

Benefits

• Compact size for space-constrained applications
• Reliable connection for signal integrity
• Prevents mis-mating with polarized design
• Durable construction for long-term performance
• RoHS compliant for environmental friendliness

Additional Details

The B4B-XH-AM(LF)(SN) connector has a contact pitch of 2.5mm. The housing material is typically made of nylon, providing good insulation and mechanical strength. The current rating is typically around 3A AC/DC, and the voltage rating is around 250V AC/DC. The connector is designed for through-hole mounting onto a printed circuit board. Mating connectors include XH series crimp style housings with compatible terminals. The shrouded header provides protection to the contacts and aids in proper alignment during mating.
