LL4148

Part No LL4148
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 100V 200MA SOD80
Datasheet
LL4148 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 200mA
Mounting SMD (SMT)
Operating Temperature - Junction -55°C to 175°C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing
Quantity per package 2,500
Case / Package SOD-80
Capacitance @ Vr, F 4pF @ 0V, 1MHz
Current - Reverse Leakage @ Vr 25nA @ 20V
Reverse Recovery Time (trr) 4ns
Voltage - Forward (Vf) (Max) @ If 1V @ 10mA
Win Source Part Number 002530-LL4148
Operating Temperature - Junction -50°C ~ 175°C
Supplier Device Package SOD-80C
Speed Small Signal =< 200mA (Io), Any Speed
Package Tape & Reel (TR);Cut Tape (CT)
Supplier Device Package Mini MELF
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Average Rectified (Io) 450mA
Package Tape & Reel (TR)
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 75V
Voltage - Forward (Vf) (Max) @ If 1V @ 50mA
Current - Reverse Leakage @ Vr 5µA @ 75V
Grade -
Mounting Type Surface Mount
Package / Case DO-213AC, MINI-MELF, SOD-80
Operating Temperature - Junction -65°C ~ 175°C
Current - Average Rectified (Io) 150mA
Ultra Librarian 3D Model Ultra Librarian LL4148 CAD Model

Description

The Fairchild/ON Semiconductor LL4148 is a standard diode type that is used in signal processing applications.

  • Voltage Rating: 100V
  • Average Rectified Current: 200mA
  • Forward Voltage: 1V @ 10mA
  • Reverse Recovery Time: 4ns
  • Popularity: Low
  • Package: SOD-80
  • Status: Active
  • Popularity: High
  • Operating Temperature Range: -55°C to 175°C
