SP3072EEN-L/TR Real Image SP3072EEN-L/TR real image6373 SP3072EEN-L/TR Real Image1 SP3072EEN-L/TR Real Image2
SP3072EEN-L/TR Real Image SP3072EEN-L/TR real image6373 SP3072EEN-L/TR Real Image1 SP3072EEN-L/TR Real Image2
Same model may have multiple batches, images only for reference.

SP3072EEN-L/TR

Part No SP3072EEN-L/TR
Manufacturer Exar Corporation
Catalog Interface - Drivers, Receivers, Transceivers
Description Single Transmitter/Receiver RS-422/RS-485 8-Pin SOIC N T/R / IC TXRX RS485/RS422 ESD 8SOIC
Datasheet
SP3072EEN-L/TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Exar Corporation
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 100mV
Data Rate 250kbps
Supply Voltage - Operating 3.3V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 030602-SP3072EEN-L/TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name SP3072E
Introduction Date March 02, 2005
ECCN EAR99
Country of Origin China
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SP3072EEN-L/TR CAD Model

Description

The Exar Corporation SP3072EEN-L/TR is a half duplex transceiver designed for use in RS422 and RS485 protocols.

  • Driver/Receiver: One driver and one receiver
  • Data Rate: Up to 250kbps
  • Receiver Hysteresis: 100mV
  • Operating Temperature Range: -40°C to 85°C
  • Package: 8-SOIC
  • Operating Voltage: 3.3V
