HLMP-6305-L0021 Real Image
Same model may have multiple batches, images only for reference.

HLMP-6305-L0021

Part No HLMP-6305-L0021
Manufacturer Broadcom Limited
Catalog LED Indication - Discrete
Description LED RED 626NM 2SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Optoelectronics
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Color Red
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 40mcd
Lens Style/Size Round with Domed Top, 1.78mm
Forward Voltage 1.8V
Current - Test 10mA
Viewing Angle 28°
Mounting SMD (SMT)
Wavelength - Dominant 626nm
Wavelength - Peak 635nm
Case / Package Yoke Lead
Height (Max) 2.92mm
Win Source Part Number 016991-HLMP-6305-L0021
Popularity Medium
Supply and Demand Status Balance
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian HLMP-6305-L0021 CAD Model

Description

The HLMP-6305-L0021 is a surface-mount LED manufactured by Broadcom Limited. It is a red LED with a clear lens and a round, domed top measuring 1.78mm in size.

  • Forward Voltage: 1.8V
  • Viewing Angle: 28 degrees
  • Millicandela Rating: 40mcd
  • Wavelength-Dominant: 626nm
  • Peak Wavelength: 635nm
  • Packaging: Reel
  • Quantity per Package: 1,500
