NE5532DR Real Image NE5532DR real image NE5532DR label picture NE5532DR real image4037
NE5532DR Real Image NE5532DR real image NE5532DR label picture NE5532DR real image4037
Same model may have multiple batches, images only for reference.

NE5532DR

Part No NE5532DR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 10MHZ 8SOIC
Datasheet
NE5532DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 9 V/μs
Gain Bandwidth Product (GBP) 10MHz
Current - Input Bias 200nA
Voltage - Input Offset 500μV
Operating Supply Current 8mA
Channel Output Current 38mA
Supply Voltage - Operating ±5 V to 15 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 025189-NE5532DR
Family Name NE5532
Introduction Date September 01, 2011
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian NE5532DR CAD Model

Description

The NE5532DR from Texas Instruments is a high-performance, low-noise operational amplifier that is designed to offer a perfect balance of specifications necessary for superior performance in a wide range of audio and data acquisition applications.

  • Bandwidth: 10 MHz
  • Slew rate: 9 V/µs
  • Noise figure: 4 nV/√Hz
  • Supply voltages: from ±3V to ±20V
  • Package: small-outline integrated circuit (SOIC)
  • RoHS compliant: free from hazardous substances and safe for use
