PDTC143ZT,215 Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

PDTC143ZT,215

Part No PDTC143ZT,215
Manufacturer Nexperia USA Inc.
Catalog Transistors (BJT) - Single, Pre - Biased
Description TRANS PREBIAS NPN 250MW TO236AB
Datasheet
PDTC143ZT,215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single, Pre-Biased Bipolar Transistors
Mfr Nexperia USA Inc.
Series Automotive, AEC-Q100
Package Tape & Reel
Product Status Active
Transistor Type NPN - Pre-Biased
Current - Collector (Ic) (Max) 100 mA
Voltage - Collector Emitter Breakdown (Max) 50 V
Resistor - Base (R1) 4.7 kOhms
Resistor - Emitter Base (R2) 47 kOhms
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 10mA, 5V
Vce Saturation (Max) @ Ib, Ic 100mV @ 250µA, 5mA
Current - Collector Cutoff (Max) 1µA
Frequency - Transition 230 MHz
Power - Max 250 mW
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package TO-236AB
Base Product Number PDTC143
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.21.0075
Win Source Part Number 843544-PDTC143ZT,215
Ultra Librarian 3D Model Ultra Librarian PDTC143ZT,215 CAD Model

Description

The PDTC143ZT,215 is a NPN Pre-Biased Bipolar Transistor from Nexperia USA Inc.

  • Application: Automotive
  • Standard: AEC-Q100
  • Mounting Type: Surface Mountable
  • Package: TO-236-3, SC-59, SOT-23-3
  • Maximum Power Rating: 250 mW
  • Voltage Breakdown: 50 V
  • Maximum Collector Current: 100 mA
  • DC Current Gain: 100 @ 10 mA and 5V
  • Vce Saturation: 100mV @ 250µA Base Current and 5mA Collector Current
  • Cutoff Current: 1µA
  • Transition Frequency: 230 MHz
  • Standard Package: 3,000 pieces
