ACPL-217-560E

Part No ACPL-217-560E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3KV TRANSISTOR 4-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3000Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 4-SO
Win Source Part Number 051563-ACPL-217-560E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian ACPL-217-560E CAD Model

Description

Product Overview

Offering precision and reliability, the ACPL-217-560E optocoupler is an essential component for systems requiring high data integrity and isolation.

Features and Benefits

  • High precision: Accurate data transmission across isolated boundaries.
  • Enhanced ruggedness: Suitable for use in rugged environmental conditions.
  • Low input drive current: Efficient power use in constrained spaces.

Applications

  • Power grid equipment
  • Aerospace systems
  • Embedded electronic devices

Additional Details

The ACPL-217-560E's robust design and high precision make it an excellent choice for critical systems where error prevention and signal clarity are paramount.
